14
INSTRUMENTS AND INDICATORS
The indicators are contained in the instrument
panel. Their functions are described in the tables on
the following pages.
USA model:
Odometer and tripmeter read in miles.
Canadian model:
Odometer and tripmeter read in kilometers.
(1) Speedometer
(2) Odometer
(3) Left turn signal indicator
(4) Side stand indicator
(5) High beam indicator
(6) Digital clock
(7) Tachometer
(8) Tachometer red zone
(9) Neutral indicator
(10) Right turn signal indicator
(11) Fuel indicator
(12) Fuel gauge
(13) Coolant temperature gauge
(14) Low oil pressure indicator
(15) Tripmeter
(16) Tripmeter reset knob
