Honeywell 5110 - Working Orientation

4 - 25
Working Orientation
Some bar codes are direction-sensitive. For example, Kix codes and OCR can
misread when scanned sideways or upside down. Use the working orientation
settings if your direction-sensitive codes will not usually be presented upright to
the scanner.
Default = Upright.
Upright:
Rotate Clockwise 90°:
Upside Down:
Rotate
Counterclockwise 90°:
* Upright
Rotate Clockwise 90°
Upside Down
Rotate Counterclockwise 90°
