HONEYWELL MODEL 700/800 SIGNAL PROCESSOR AND VIEWING HEAD
27 66-2069EP—08
Fig. 19. Flow Chart 1 - Setting Factory Defaults.
IS THE PANEL LOCKED?
LOAD
FACTORY
DEFAULTS
PRESS LOAD FACTORY DEFAULTS
FOR 2 SECONDS
2 SECS
IS THE AUTO SET
LIGHT LIT?
DISPLAY SHOWS ‘PL’,
MEANING THE PANEL IS LOCKED
DISPLAY SHOWS ‘CF’,
MEANING CONFIRM
RELAY ON 16
RATIO 50%
0-20/4-20mA OPTION 4-20mA
FFRT 1 SEC
NORMAL OPERATION
N
RESTORING DEFAULT VALUES
Y
N
Y
OR
M34456A
PRESS RESET OR WAIT 4 SECONDS TO CANCEL
CHANGING THE AUTO SET VALUES
RE
S
ET
r
E
PRESS LOAD FACTORY DEFAULTS AGAIN TO CONFIRM
YOU WANT TO CHANGE THE AUTO SET VALUES
LOAD
FACTORY
DEFAULTS
NORMAL OPERATION
