HONEYWELL MODEL 700/800 SIGNAL PROCESSOR AND VIEWING HEAD
66-2069EP—08 28
Fig. 20. Flow Chart 2 - Auto Setup Page 1.
IS THE PANEL LOCKED?
IS THE AUTO SET
LIGHT LIT?
IS THE FLAME ON
LIGHT LIT?
CONTINUED NEXT PAGE
DISPLAY SHOWS ‘PL’
UNTIL KEY RELEASED
DISPLAY SHOWS ‘CF’,
MEANING CONFIRM
DISPLAY SHOWS ‘BO’,
MEANING BURNER OFF
NORMAL OPERATION
N
AUTO SETUP
Y
N
N
Y
Y
OR
M34458B
PRESS RESET OR WAIT 4 SECONDS TO
CANCEL AUTO SETUP
RESET
rE
PRESS RESET TO CANCEL AUTO SETUP
RESET
rE
PRESS BNR-ON SEQ AGAIN TO CONFIRM YOU
WANT TO BEGIN TAKING DATA FOR AUTO SETUP
BNR-ON
SEQ
START/END
BNR-ON
SEQ
START/END
PRESS BNR-ON SEQ
FOR 2 SECONDS
2 SECS
