HONEYWELL MODEL 700/800 SIGNAL PROCESSOR AND VIEWING HEAD
5 66-2069EP—08
Fig. 1. Model 700ACSP Signal Processor Wiring.
APPROVED
AC IN
GROUND
TO VIEWING
HEAD
24 V
BACKUP BATTERY
(OPTIONAL)
0-20 OR 4-20 MA
FOR INDICATOR OR
INSTRUMENTATION
360 OHMS MAX
+
-
+
-
CHASSIS,
EARTH, OR
SYSTEM GND
M34280A
+
+26VDC
GND
.125 A
.4A
2
A
AC POWER
SUPPLY
-t°
