BENDIX/KING KN 62/62A/64
Rev 7, November/2004 00144I06.TDC Page 1-2
NOTE
*THE MAXIMUM RANGE AT WHICH THE DME
WILL LOCK UP IS DETERMINED BY ALTITUDE
AND GROUND STATION OUTPUT POWER AND
SENSITIVITY.
SPECIFICATION CHARACTERISTIC
D. Gas discharge display
OUTPUT POWER: 50 watts peak, pulsed power minimum (35 watts,
KN 64)
100 watts nominal (50 watts, KN 64)
MAXIMUM DISPLAY RANGE:* 389 nautical miles
PANEL HEIGHT: 1.3 inches (3.30 cm) maximum
ACQUISITION SENSITIVITY: -82dBm minimum, -87dBm nominal
(-78dBm minimum, -87dBm nominal, KN 64)
SPECIFICATION CHARACTERISTIC
RANGE ACCURACY:*
±
.1 NAUTICAL MILES OR ± .14%, WHICH-
EVER IS GREATER, FROM 0 TO 99.9 NAU-
TICAL MILES
±
1 NAUTICAL MILE FROM 100 TO 389
NAUTICAL MILES
GROUND SPEED ACCURACY:
±
1 KNOT OR ± 1%, WHICHEVER IS
GREATER FROM 0 TO 999 KNOTS
TIME-TO-STATION ACCURACY:
±
1 MINUTE FROM 0 TO 99 MINUTES
SEARCH TIME: 1.0 second nominal
MEMORY TIME: 11 to 15 seconds
AUDIO OUTPUT (IDENT): Level adjustable up to 15mW INTO 600 OHM
LOAD, nominally set for 2mW
MAXIMUM ALTITUDE: 50,000 feet
KN 62/62A/64 OVERALL DIMENSIONS (in-
cluding mounting rack and connectors)
LENGTH 12.258 INCHES (31.135 cm)
WIDTH: 6.312 inches (16.032 cm)
HEIGHT: 1.300 inches ( 3.302 cm)
WEIGHT: 2.6 LBS (1.18 KG) nominal
