BENDIX/KING KN 62/62A/64
Rev 7, November/2004 00144I06.TDC Page 2-9
TABLE 2-1 KN 62/62A/64 PIN FUNCTION LIST
A --------------------- ! AUDIO LOW
B --------------------- ! AUDIO HI
C --------------------- DME COMMON
D --------------------- ! SLIP CODE SELECT
E --------------------- +14vdc LIGHT DIMMER
F --------------------- +28vdc LIGHT DIMMER SELECT
H <-- --------------------- K400/KE/K1 DME CHANNEL LINE
J --------------------- ! 2X5 CODE SELECT
K --------------------- ! 10 BIT FREQUENCY
L <-- --------------------- ! RNAV/CHAN REQ
M --------------------- BCD CODE SELECT
N <-- --------------------- DME REQUEST
P --------------------- RESERVED
R <-- --------------------- ALTITUDE REQUEST
S --------------------- GROUND
1 --------------------- A/C GROUND
2 --------------------- A/C POWER
3 --------------------- A/C POWER
4 <-- --------------------- K200/KC/K2 CHANNEL LINE
5 <-- --------------------- K50/K50/K50 CHANNEL LINE
6 <-- --------------------- K100/KD/K3 CHANNEL LINE
7 <-- --------------------- K800/KA/K0 CHANNEL LINE
8 <-- --------------------- M1/MD/D3 CHANNEL LINE
9 <-- --------------------- M2/MC/M2 CHANNEL LINE
10 --------------------- NO CONNECTION
11 <-- --------------------- M4/ME/M1 CHANNEL LINE
12 <-- --------------------- M8/MA/M0 CHANNEL LINE
13 <-- --------------------- DATA BUS
14 <-- --------------------- CLOCK BUS
15 --------------------- A/C GROUND
IN OUT
