BENDIX/KING KN 62/62A/64
Rev 7, November/2004 00144I06.TDC Page 1-3
1.3.1 DME CHANNEL SOURCES
The KN 62/62A/64 can be channeled by the internal channeling tunning knobs or it may be chan-
neled by an external source. The KN 62/62A/64 will accept external channeling in the form of
Shifted BCD, ARINC 2X5, or Bendix/King Slip code. The tunning logic for each of the three types
of channeling is given in tables 1-1, 1-2, and 1-3.
TABLE 1-1 SHIFTED BCD DME CHANNELING CODES
0 = Connected to Remote Control Common
1 = Open
POWER REQUIREMENTS: 11-33VDC at 15 watts
066-1068-04 AND 066-1088-01 ONLY
BACKLIGHTING: NOMINAL 14VDC AT 2 WATTS
NOMINAL 28VDC AT 2 WATTS
CHANNELING SOURCES: a. Internal
b. External control head providing shifted
BCD code such as KFS 560B.
c. External control head providing ARINC 2 x
5 code such as KX 170 and KFS 560B.
d. External control head providing slip code
such as KX 170A, KX 170B, KX 175A, and KX
175B.
Frequency
Mhz
M8 M4 M2 M1 .X
Mhz
K80
0
K40
0
K20
0
K10
0
.XX
Mhz
K50
108 0000.0X0000.X01
109 0001.1X0001.X50
110 0010.2X0010
111 0011.3X0011
112 0100.4X0100
113 0101.5X0101
114 0110.6X0110
115 0111.7X0111
116 1000.8X1000
117 1001.9X1001
