MERLIN NX IP AND MST/TP VAV CONTROLLER - INSTALLATION INSTRUCTIONS
EN1Z-1076GE51 R0722 2
GENERAL
Trademark Information
Sylk™ is a trademark of Honeywell International Inc.
BACnet® is a registered trademark of ASHRAE Inc
Product Description
The CLMEVAxxxx24NM IP and MSTP VAV controller with
integrated actuator and air flow sensor are a part of the
MERLIN NX family.
The MERLIN NX family of room controllers offers
performance-based engineering with ARENA NX (Niagara
eXtended) and enables Single-Tool-Engineering throughout
the whole Building Management System and allowing cost-
effective installation and commissioning and driving new
levels of functionality and efficiency in today's buildings.
These scalable and freely programmable BACnet/IP and
BACnet MS/TP based unitary controllers utilize smart
engineering and commissioning tools. It supports multiple
flexible configurations to address specific applications with
ARENA NX (Niagara) tool, Modbus, and Sylk™ bus sub-
bus integration options.
Fig. 1. Controller Part Numbers Description
Table 1. ordering part number
Part Number UIO SSR Sum IO Backbone Comm. DIP switch BLE integrated
CLMEVA75I24NM 7 5 12 IP No No
CLMEVA00IB24NM 0 0 0 IP No Yes
CLMEVA75IB24NM 7 5 12 IP No Yes
CLMEVA75M24NM 7 5 12 MS/TP Yes No
CLMEVA00MB24NM 0 0 0 MS/TP Yes Yes
CLMEVA75MB24NM 7 5 12 MS/TP Yes Yes
Table 2. Replacement Parts
Part Number Comments
SDPPF500PA Spare part used in case, original air flow sensor gets damaged.
ANT-REM
Use the remote antenna if the antenna mounted on the controller does not provide reliable
communication due to environmental conditions. The packet contains four antennas.
Table 3. Mobile Application
Honeywell Connect Mobile
application
Honeywell Connect Mobile application for the VAV balancing can be downloaded from the Google
Play Store / Apple App store.
Brand Identifier
A 7 5 I B 24 N M
Universal Inputs
Digital Outputs (SSR)
Niagara
Power Supply
BLE
I - IP
