MERLIN NX IP AND MST/TP VAV CONTROLLER - INSTALLATION INSTRUCTIONS
7 EN1Z-1076GE51 R0722
Controller Terminals
Type Legend Printing Description
Power
1 Earth Ground (Connected to power earth ground)
2 V0 Ground
3 ~ Power supply voltage (Connected to 24VAC~)
4 AC OUT 24VAC~ output
5 SR IN SSR POWER input (Connected to terminal 4 (AC OUT) by a jumper wire)
SSR
6 SR1 SSR1 output (if SSR1 is on this pin should be 24VAC~)
7 C Ground
8 SR2 SSR2 output (if SSR2 is on this pin should be 24VAC~)
9 SR3 SSR3 output (if SSR3 is on this pin should be 24VAC~)
10 C Ground
11 SR4 SSR4 output (if SSR4 is on this pin should be 24VAC~)
12 SR5 SSR5 output (if SSR5 is on this pin should be 24VAC~)
13 C Ground
SYLK
14 WM1 Interface for Sylk™ bus
15 WM2 Interface for Sylk™ bus
RS
485
16 + RS 485 Modbus interface
17 - RS 485 Modbus interface
18 COM Ground
UIO
19 IO1
Universal signal input/output1 (Input<"0-20mA" "0-10V" "NTC10K" NTC20K" "RTD" >; Output<"0-
10V" "0-20mA">
20 C Ground
21 IO2
Universal signal input/output2 (Input<"0-20mA" "0-10V" "NTC10K" NTC20K" "RTD" >; Output<"0-
10V" "0-20mA">
22 IO3
Universal signal input/output3 (Input<"0-20mA" "0-10V" "NTC10K" NTC20K" "RTD" >; Output<"0-
10V" "0-20mA">
23 C Ground
24 IO4
Universal signal input/output4 (Input<"0-20mA" "0-10V" "NTC10K" NTC20K" "RTD" >; Output<"0-
10V" "0-20mA">
25 IO5
Universal signal input/output5 (Input<"0-20mA" "0-10V" "NTC10K" NTC20K" "RTD" >; Output<"0-
10V" "0-20mA">
26 C Ground (Connected to 24VAC~ground)/System ground
27 IO6
Universal signal input/output6 (Input<"0-20mA" "0-10V" "NTC10K" NTC20K" "RTD" >; Output<"0-
10V" "0-20mA">
28 C Ground
29 IO7
Universal signal input/output7 (Input<"0-20mA" "0-10V" "NTC10K" NTC20K" "RTD" >; Output<"0-
10V" "0-20mA">
20 VDC
30 C Ground
31
20 VDC
OUT
20VDC power output
BACnet
MS/TP
32
(a
+ Signal for RS 485 bus +
33
(a
- Signal for RS 485 bus -
34
(a
COM Ground
IP ethernet RJ45-1/RJ45-2
(b
(a
Terminal 32,33, and 34 are available in MSTP variant only.
(b
Terminal for IP variant only.
