Honeywell CO60PM Service Manual

CONFIDENTIAL
Website: http://www.honeywellaircoolers.com
2
CONTENT
1. Preface
1.1. Safety Precautions
1.2. Insulation Resistance Test
1.3. Specifications
1.4. Features
1.5. Warning & Safety Rules
1.6. Parts Description
1.7. Operations
1.8. Cleaning & Maintenance
2. Disassembly Instructions
2.1. How To Change Honeycomb Cooling Media
2.1.1. Back Panel
2.1.2. Back Honeycomb Cooling Media
2.1.3. Right Side Panel
2.1.4. Right Side Honeycomb Cooling Media
2.1.5. Left Side Panel
2.1.6. Left Side Honeycomb Cooling Media
2.2. How To Change Switch
2.2.1. Switch Box
2.2.2. Switch(cool/speed/swing)
2.2.3. Wiring Color Connection
2.3. How To Change Water Pump
2.3.1. Water pump pipe and water pump clip
2.3.2. Cool Switch And Wiring Connector
2.3.3. Water Pump Wiring Connection
2.4. How To Change Main Motor
2.4.1. Speed Switch And Wiring Connector
2.4.2. Fan Blade And Fan Motor
2.4.3. Main Motor Wiring Connection
2.5. How To Change Swing Motor
2.5.1. Swing Switch And Wiring Connector
2.5.2. Swing Motor And Swing Motor Wheel
2.5.3. Swing Motor Wiring Connection
3. Troubleshooting Guide
3.1. Outside Dimensions
3.2. Cooling System
3.3. Troubleshooting Guide
4. Schematic Diagram
4.1. Wiring Diagram
4.2. Wiring Color Description
5. Exploded View
6. Replacement Parts List

Honeywell CO60PM Specifications

General

Type	Monobloc mobile air conditioner
Noise level	- dB
Cooling capacity (max)	- BTU/h
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	-
Product color	Grey, Taupe
Hourly energy consumption (cooling)	- kWh

Weight and Dimensions

Depth	466 mm
Width	700 mm
Height	1017 mm
Weight	17800 g
Package depth	502 mm
Package width	736 mm
Package height	1053 mm
Package weight	22000 g
