Honeywell CT3600 User Manual

23 69-1642
Notice:
This thermostat is a Class B digital apparatus that complies with Canadian Radio Interference Regulations,
CRC c. 1374.
M1061
9
THERMOSTAT
1 POWER SUPPLY. PROVIDE
DISCONNECT MEANS AND OVERLOAD
PROTECTION AS REQUIRED.
1
1
5-WIRE HEAT/COOL
(JUMPER REMOVED)
HEATING
RELAY OR
VALVE COIL
COOLING
CONTACTOR
COIL
FAN
RELAY
B
R
RC OW Y
G
M1873
8
HEAT
RELAY
COMPRESSOR
CONTACTOR
COOL
DAMPER
1
POWER SUPPLY. PROVIDE
DISCONNECT MEANS AND
OVERLOAD PROTECTION
AS REQUIRED.
1
5-WIRE HEAT/COOL WITH DAMPER
(JUMPER INTACT)
B
R
RC OW Y
G
FAN
RELAY
HEAT
DAMPER
THERMOSTAT

Honeywell CT3600 Specifications

General

Brand	Honeywell
Model	CT3600
Category	Thermostat
Language	English
