Honeywell DOLPHIN 6100 User Manual

8 - 5
• Proxy server connection
Note: If you are connected to your ISP or private network during synchronization, the terminal should
download the proper proxy settings during synchronization with the workstation. If these settings are
not on your workstation or need to be changed, ask your ISP or network administrator for the proxy
sever name, server type, port, type of Socks protocol used, and your user name and password.
To complete the setup screens, obtain the network parameters from your system administrator.
Modify an Existing Connection
Manage Existing Connections appears on the Connections tab after at least one network connection
has been established.
Tap Manage Existing Connections on the Horizontal scroll and follow the setup screens.
Advanced
The Advanced screen enables you to select the default network, dialing rules, and IP address exceptions
for modem connections.
Note: You should not need to change Advanced settings because most ISPs now use DHCP addresses.

Honeywell DOLPHIN 6100 Specifications

General

Touchscreen	-
Display diagonal	2.8 \
Display resolution	240 x 320 pixels
Display number of colors	65536 colors
Internal memory	0.128 GB
Compatible memory cards	MicroSDHC
Processor family	PXA 300
Processor frequency	0.624 GHz
Processor manufacturer	Marvell
Product color	Grey, Stainless steel
Barcode reader	Yes
Phone function	No
Wi-Fi standards	802.11b, 802.11g
Bluetooth version	2.0+EDR
Interface	USB 1.1
RS-232 input ports	1
Battery capacity	2200 mAh
Battery life (max)	8 h
Battery recharge time (off)	4 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Bundled software	Honeywell Powertools and Demos
Operating system installed	Windows CE 5.0

Weight and Dimensions

Depth	66 mm
Width	175 mm
Height	26.8 mm
Weight	250 g
