Honeywell Domonial CMI Series User Manual

Page 22 of 52
02/2011
E
N
G
L
I
S
H
4-RF Keyfob 800M range (type F31): TCB800M, TCB8M, TCBPA8M, TCC800M, TCC8M
User
403
1323
User 1 (Master) = 0, User 2 = 1, User 3 = 2, ..User 10 = 9
0
Zone
401
19 120
0 = Total (Annex inhibited)
2 = Annex
3 = Total + Annex
3
Alert
402
19 223
0 = Inactive
1 = Alert 1
2 = Alert 2
3 = Alert 3
0
Control (key #4)
411
19 326
0 = NO FUNCTION
1 = Arm total set
2 = Disarm total & partial sets
3 = Arm partial set
4 = Arm annex set
5 = Disarm annex set
6 = Drive Receiver 1
7 = Drive Receiver 2
8 = Drive Receiver 3
9 = Drive Receiver 4
10 = Drive Receiver 5
11 = Drive Wired Output
13 = Alert 1
14 = Alert 2
15 = Alert 3
0
Control + Arm (4 + 1)
412
19 429
4
Control + Disarm (4 + 2)
413
19 522
5
Control + Part arm (4 + 3)
414
19 625
0
4-RF Keyfob 800HF range (type F): TC805HF
User
403
1323
User 1 (Master) = 0, User 2 = 1,
User 3 = 2, … User 10 = 9.
0
Function
415
1425
According to the following table
10
(On/Off_T/P/RS/Alert 1)
Associated receiver
416
1629
0 to 34. 255 for None.
Function/Key
1
2
3
4
1+3
0
Arm total set
Disarm all
Arm Partial set
Alert 3
No effect
1
Arm annex set
Unset annex
2
Arm Partial set
Alert 1
3 to 5
Arm Partial set
Receiver
Alert 1 to 3
6 to 8
Arm annex set
Receiver
Alert 1 to 3
9
Arm Partial set
Alert 1
Alert 3
10 to 12
Disarm total & part
sets
Arm Partial set
Receiver
Alert 1 to 3
13
Arm Partial set
Alert 2
Alert 1
