Honeywell equIP H2W2GR1 - Page 90

2MP/4MP Low Light WDR IP Camera User Guide
78
ELECTRICAL
POWER SUPPLY
PoE(802.3af) Class 0/12VDC/24VAC
LONG DISTANCE POE SUPPORT
3X POE (300m @100Mbps)
AC FREQUENCY
50/60 Hz
POWER CONSUMPTION
HCW2GV: Max 10W
HCL2GV: Max 9.5W
AUXILIARY POWER SUPPLY
2.0W, DC12V (+/-5%)
MECHANICAL
DIMENSIONS
125.0×75.8×69.0 mm (4.92×2.98×2.72 in.)
WEIGHT
HCW2GV: Product weight: 535g (1.18lb); Package Weight:
756g (1.67lb)
HCL2GV: Product weight: 534g (1.18lb); Package Weight:
755g (1.66lb)
CONSTRUCTION
Die-cast aluminum housing with powder coat
CONSTRUCTION COLOUR
RAL 9003 (White) and RAL 7022 (Grey)
ENVIRONMENTAL
OPERATING TEMPERATURE
–30°C to 60°C (–22°F to 140°F)
RELATIVE HUMIDITY
0% to 95%, non-condensing
REGULATORY
EMISSIONS
FCC Part 15, CE (EN 55032); Complies with RCM (AS/NZS)
IMMUNITY
CE (EN 50130-4)
SAFETY
North America UL Listed to UL/CSA 60950-1, CE (EN
60950-1)
ROHS
EN50581
