Excel 800 LION
63 EN1B-0375GE51 R0308
Default Service Type
The default service type of these variables is
unacknowledged.
Analog Sensor Output – nvoAiValuePct[ ]
This network variable output represents the percentage
level for the appropriate input, if configured for voltage input.
Valid Ranges for 0 … 10 V Input
Value Representation
< 0 V 0 %
0 V … 10 V 0 … 100 %
> 10 V 100 %
Table 61 Analog input values: 0 … 10 V
Valid Ranges for 2 … 10 V Input
Value Representation
< 1.5 V Sensor break/short circuit
1.5 V … 2 V 0 %
2 V … 10 V 0 … 100 %
> 10 V 100 %
Table 62 Analog input values: 2 … 10 V
Default Value
The default value is set after power-up or reset and remains
until the module has measured a valid value.
nvoAiValuePct = INVALID = 0x7FFF (=163.835 %)
The sensor failure behavior can be configured for 2 … 10 V.
Temperature Sensor Output – nvoAiTempP[ ]
This network variable output represents the temperature for
the appropriate input, if configured for temperature sensor,
except PT1000-2.
Range: see Table 43 and Table 44 on page 41.
Default Value
The default value is set after power-up or reset and remains
until the module has measured a valid value.
nvoAiTempP = INVALID = 0x7FFF (= 327.67 °C)
Slow Digital Input – nvoAiSwitch[ ]
This network variable output represents a slow digital input
connected to the universal input terminals.
Valid Range
Sensor Value State
Enabled 100 % 1
Disabled 0 % 0
Not configured 0 % -1
Table 63 Slow digital input values
Temperature#2 Sensor Output – nvoAiTemp[ ]
This network variable output represents the temperature for
the appropriate input, if configured for temperature sensor if
configured for PT1000-2 sensor.
Range: see Table 43 and Table 44 on page 41.
Default Value
The default value is set after power-up or reset and remains
until the module has measured a valid value.
nvoAiTemp = INVALID = 0xFFFF (= 6279.5 °C)
