Honeywell F300 Professional Installation Guide

APPENDICES
Replacement Parts
No. Description
Nominal Return Air Opening
16 x 20 in.
(406 x 508 mm)
16 x 25 in.
(406 x 635 mm)
20 x 12-1/2 in.
(508 x 318mm)
20 x 20 in.
(508 x 508 mm)
20 x 25 in.
(508 x 635 mm)
1 F300 Door includes No. 2 32007528-003 N/A 32007528-003
2 Test Button Assembly 137980A (1)
3 Electronic Cell FC37A1114 (2) FC37A1130 (2) FC37A1064 (1) FC37A1049 (2) FC37A1064 (2)
4 Cell Handle 137266 (2) 137266 (2) 137266 (1) 137266 (2) 137266 (1)
5 Prelter (without spring
clips)
209989 (2) 209989 (2) 209989 (1) 209989 (2) 209989 (2)
6 Cell Key 136518 (1)
7 F300 Power Box Assembly
Series Two
b
. Includes No.
8-20. 120V, 60 Hz. White
Cover.
PS1201B20 (1) PS1201B25 (1) PS1201B12
d
PS1201B20 (1) PS1201B25 (1)
240V, 60 Hz
c
PS2401B12
b
8 Switch 203321 (1)
10 F300 Power Supply, Series
Two
b
. 120V, 60 Hz
PS1201A00 (1)
240V, 60 Hz N/A
c
11 Interlock Bracket and
Switch
4074ETG (1)
13 Terminal Board Assembly
Front
203329B (1) 203329B (1) N/A N/A 203329B (1)
14 Terminal Board Assembly
Rear
203329A (1) N/A 203329A (1)
17 Line Cord 4074ETD (1)
19 Neon Assembly 4074EYS (1)
20 Airow Switch, pin
connection
4074ETH (1)
Airow Switch, plug
connection
4074EZB (1) N/A 4074EZB (1)
21 FC37A Bag Assembly
for cell repair. Contains:
2 Connector Clips, 1
Terminal Board and
instructions
4074EHG
22 Post Filter (optional) 50000293-001 50000293-002 50000293-004 50000293-003 50000293-004
b
Series Two compatible with W8600F.
c
Use 203365A Conversion Kit for changing 120V, 60 Hz model to 240V, 60 Hz.
d
Change from white cover to black cover as a running change. Use original cover for color match.
(#) = Quantity required per unit.
N/A = Not available as merchandised part.
F300 Electronic Air Cleaner 68-0240EF—07
23
68-0240EF_B.indd 23 9/14/11 3:04 PM

Honeywell F300 Specifications

General

Type	Electronic Air Cleaner
Voltage	120V
Filter Type	Electronic
Warranty	5 year limited warranty
Collection Cell	Aluminum
Pre-filter	Washable
Wattage	15W
