F57A,B FLUSH-MOUNT COMMERCIAL ELECTRONIC AIR CLEANER
19 68-0083—07
PARTS LIST
See Fig. 22 for exploded view of parts listed.
PARTS NOT SHOWN IN DIAGRAM
Ref. No Description
F57A F57B
120Va.c. ,60Hz
220~240Va.c.,
50Hz 120Va.c. ,60Hz
220~240Va.c.,
50Hz
1 Grille assembly 196114B 196114B 220364A 220364A
2 Pre filter 195910 195910 198571 198571
3 Electronic Cell FC37B1030/U FC37B1030/U FC37B1030/U FC37B1030/U
4 Fan 196205 196205 220393 220393
5 Motor assembly(include motor,
motorbracket, four isolation
bushings)
32002456-TA 32002457-TA 198673-TA 200813-TA
6 Control swich, knob 50046872-001 50046872-001 50046872-001 50046872-001
Rotary swich, 50046335-001 50046335-001 50046335-001 50046335-001
6a Infrared receiver – 203904A – 203904A
7 Performance switch 196214 196214 196214 196214
8 Interlock switch 203324 196227 203324 196227
9 Power supply assembly 42009287AP 42009287AP 42009287AP 42009287AP
10 Vinyl strips(2pcs required) 196150 196151 196150 196151
11 Vinyl strips(2pcs required) 196151 196151 196151 196151
12 Motor bracket 202791-T 202791-T 202791-T 202791-T
Wash Led bag assembly 4074EMH 4074EMH
Contact board assembly 190912A (2pcs required) 190912A
Ionizer Wires 136434AA 136434AA
Carbon filter 195911 (2pcs required) 198672
