F57A,B FLUSH-MOUNT COMMERCIAL ELECTRONIC AIR CLEANER
68-0083—07 2
SPECIFICATIONS
IMPORTANT
The specifications given in this publication do not
include normal manufacturing tolerances. There-
fore, this unit may not exactly match the listed
specifications. This product is tested and calibrated
under closely controlled conditions, and some
minor differences in performance can be expected
if those conditions are changed.
Models:
F57A Flush-Mount Commercial Electronic Air Cleaner:
contains two FC37B heavy duty commercial cells, power
supply assembly, prefilter, inlet-outlet grille, power and
speed control switch, performance selection switch, col-
lector test button, 3-speed motor driven fan, interlock
switch for the access grille, vinyl trim flanges, exhaust
air vent and LED indication of system operation.
F57B Flush-Mount Commercial Electronic Air Cleaner:
same as F57A, except with only one FC37B heavy duty
commercial cell.
Color: Off-white.
Electrical Ratings: Voltage and Frequency: 120 Va.c.,
60 Hz; 220–240 Va.c., 50 Hz.
Current and Power Consumption:
Air Flow Capacity:
Efficiency:
Up to 95% efficiency using the Dust Spot Method measur-
ing atmospheric dust, according to the American Soci-
ety of Heating, Refrigeration, and Air Conditioning
Engineers (ASHRAE) Standard 52.1-92.
Motor:
F57A: 1/12 hp; sealed ball bearing.
F57B: 1/10 hp; sealed ball bearing.
Motor lubrication is not required.
Ambient Temperature Rating:
Shipping and Storage: minus 20°F to plus 150° F
(minus 29° C to plus 66° C).
Operating: this equipment is intended for use at ambient
temperatures which are usually not higher than 77° F
(25° C) but occasionally may be as high as 104° F
(40° C) for brief periods.
Dimensions:
See Fig. 1 and 2 for dimensions.
Shipping and Installation Weight:
Approvals:
Underwriters Laboratories Inc. Listed: File no. E30954,
Guide no. AGGZ.
Replacement Parts and Accessories:
See “Parts List” on page 19.
Product
Code
Voltage/
Frequency
Rated Air
Volume
Remote
Control
F57A1093 120V/60 Hz 875 CFM
(1500 m
3
/hr)
F57A1101 220-240V/
50 Hz
F57A1101RC •
F57B1067 120V/60 Hz 460 CFM
(780 m
3
/hr)
F57B1075 220-240V/
50 Hz
F57B1075RC •
Fan
Setting
120 Va.c., 60 Hz 220–240 Va.c., 50 Hz
AW A W
F57A HI 3.9 315 1.8 315
MED 3.2 300 1.4 250
LOW 2.4 200 1.2 205
F57B HI 4.3 255 1.9 275
MED 2.1 185 1.0 150
LOW 1.2 85 0.7 100
Fan
Setting
120 Va.c., 60 Hz 220–240 Va.c., 50 Hz
cfm m
3
/min cfm m
3
/min
F57A HI 1030 29 875 25
MED 690 20 730 21
LOW 555 16 640 18
F57B HI 485 14 460 13
MED 280 8 375 11
LOW 175 5 260 7
F57A F57B
l b kg l b kg
Heavy duty commercial
cell (each)
9.5 4.3 9.5 4.3
Shipping weight 106.0 48.1 64.0 29.0
Installed weight 83.0 37.6 54.0 24.5
