Honeywell FALCON MJ Pulse/M-Bus User Manual

Falcon MJ M-Bus Operating instructions
05/18 Generation 1.2
Page 18 of 38
34
DR3
Value
xxh
35
DR3
Value
xxh
36
DR4
DIF (8 digit BCD Stor. 1)
4Ch
37
DR4
VIF (Volume l)
13h
38
DR4
Value LSB
78h
39
DR4
Value
56h
40
DR4
Value ( = 12345,678 m³)
34h
41
DR4
Value MSB
12h
42
DR5
DIF (Date Stor. 1;Type G)
42h
43
DR5
VIF (Date + Extension)
ECh
44
DR5
VIFE (Future Value)
7Eh
45
DR5
Value
xxh
46
DR5
Value
xxh
47
DR6
DIF (8 digit BCD)
0Ch
48
DR6
VIF (Volume l + Extension)
93h
49
DR6
VIFE (backward flow)
3Ch
50
DR6
Value LSB
03h
51
DR6
Value
00h
52
DR6
Value ( = 0,003 m³)
00h
53
DR6
Value MSB
00h
54
DR7
DIF (Date Max. Value; Type G)
12h
55
DR7
VIF (Date)
6Ch
56
DR7
Value
xxh
57
DR7
Value
xxh
58
DR8
DIF (16 bit Int, Max. Value)
12h
59
DR8
VIF (Flow Rate l/h)
3Bh
60
DR8
Value
xxh
61
DR8
Value
xxh
62
DR9
DIF (16 Bit Int)
02h
63
DR9
VIF (Flow Rate l/h)
3Bh
64
DR9
Value
xxh
65
DR9
Value
xxh
66
DR10
DIF (Backflow Alarm Date; Type F)
C4h
67
DR10
DIFE (Storage No. 7)
03h
68
DR10
VIF (Date, Time)
6Dh
69
DR10
Value LSB
xxh
70
DR10
Value
xxh
71
DR10
Value
xxh
72
DR10
Value MSB
xxh
73
DR11
DIF (Manipulation Alarm Date; Type F)
84h
74
DR11
DIFE (Storage No. 6)
03h
75
DR11
VIF (Date, Time)
6Dh
76
DR11
Value LSB
xxh
77
DR11
Value
xxh
78
DR11
Value
xxh
79
DR11
Value MSB
xxh
