3.2 Info tab card
The lower third of this card is also visible in every other card. This makes the following entry
fields and control buttons continuously available:
COM-Port
specifies the serial interface of the PC to which the M-Bus level converter is
connected. This port setting will be stored in the program's INI file so that when
the program is restarted it will not be necessary to make this setting again.
Baudrate
specifies the PC's interface speed. It can be set to 300, 2400 and 9600 baud
and corresponds to the currently used M-Bus baudrate. The Falcon MJ module
supports the baud-rates 300, 2400 and 9600 WITH automatic detection, that
means the baud rate do not need to be configured and adopts automatically
to the baud rate of the M-Bus network.
New M-Bus baud-rate
permits a baud-rate changeover for the M-Bus device. To this end the
corresponding selection field is used to set a new baud-rate. Afterwards, the
module will be notified of the new baud-rate via the M-Bus.
