Installation FFT-24 Installation
3.10 FFT-24 Installation
The FFT-24 expander board is used to add 24 additional zones to the IFP-FFT
A maximum of two expanders is allowed in the system.
Figure 3.12 FFT-24 Expander Front View for Zone 25 - 48
active (green)
trouble (amber)
Zone 25-
Zone 32
Zone 33 -
Zone 40
Zone 41 -
Zone 48
Figure 3.13 FFT-24 Expander Front View for Zone 49 - 72
active (green)
trouble (amber)
Zone 49-
Zone 56
Zone 57 -
Zone 64
Zone 65 -
Zone 72
