Honeywell FSL100-TL - 13 Accessory Specifications

MAN0987_Iss 2_09/16
40
FSL100 Series Flame Detectors
Technical Handbook
CERTIFICATION
13 Accessory Specifications
FSL100-TL Safe Area Test Lamp Specifications
Lamp Housing
ABS (plastic) black
Ingress Protection rating
IP30 / NEMA 1
Adapter (charger)
100-240 Vac, 500 mA switching with plugs for US, EU, GB and AU
Battery
12 VDC / 2.8 Ah Sealed Lead Acid Battery
Lamp
H3, 12 VDC / 100 W
Temperature range
+4 to +40 ºC (+39 to +104 ºF)
Continuous Operation (Max)
10-15 minutes under optimal conditions
Operational range
Up to 4 m (13 ft)
Country of Origin/Intrastatistic Number
EU, 8531 10 30
Shipping dimensions (Lamp box)
310 x 220 x 210 mm (12.725 x 9 x 8.725 ins)
Shipping weight (Lamp)
2.1 kg (4.62 lbs)
Carrying case
Case: polypropylene, Inlay: polyurethane
Shipping dimensions (box)
440 x 340 x 280 mm (17.375 x 13.375 x 11 ins)
Shipping weight incl. test lamp
5 kg (11.1 lbs)
FSL100-TL Battery Specifications
Replacement Part No.
FSL100-TLBT
Battery Type
Rechargeable Sealed Lead-Acid Battery
Battery Voltage And Capacity
12 VDC / 2.7 Ah
Terminal Type
Spade
Dimensions
103 x 70 x 46 mm
FSL100-TLX Hazardous Area Test Lamp Specifications
Housing
Aluminium
Ingress Protection Rating
IP66
Power (Batteries)
6 VDC Nominal (4 X 1.5 VDC AA Alkaline Battery)
Operational Range
Up To 4 M (13 Ft)
Working Temperature Range
-25 To +50 °C (-13 to +122 °F)
Storage Temperature Range
-40 To + 80 °C
Country Of Origin/Intrastatistic Number
EU, 8531 10 30
Shipping Dimensions (Box)
32 X 30 X 13 cm (13 X 11 X 5 in.)
Shipping Weight
3 kg (7 lbs.)
IECEx Certificate
IECEx Zone 1
FSL100-SM21 Swivel Mount
Material Swivel / Bolts and Nuts
PA66 / 316 SS
Weight
280 grams (0.62 lbs)
Table 4. Accessory Specifications
SPECIFICATIONS
