Programming
To program the MS-95 manual pull station to the address
switch settings, set the address DIP switch on the device’s
printed circuit board. All other programming is accom-
plished at the fire alarm control panel.
Engineer’s Specifications
The analog addressable manual pull station shall contain
the electronic interface circuitry required for individual
device identification, alarm reporting and trouble supervi-
sion. It shall communicate to the main control panel via the
analog addressable circuit. The single-action station shall
consist of a die-cast aluminum housing fitted with a pull out
lever which, when operated, locks in position after activat-
ing an alarm initiating contact.
Specifications
Standby Current: 0.0008 A (0.8 mA)
Alarm Current: 0.0015 A (1.5 mA)
Operating
Temperature: 32°F to 120°F (0°C to 49°C)
Relative Humidity: 93%, non-condensing
Power: 24 VDC
Material: Die-cast aluminum
Finish: Fire alarm red, smooth gloss
enamel.
Raised cast letters are high-
lighted.
Target background for pull lever
is white glossed enamel
Dimensions:
MS-95: 4.75" H x 3.25" W x 1 1/8" D
(from the backplate)
(10.79 H x 8.25 W x 2.99 D cm)
MS-95T: 4.75" H x 3.25" W x 1 1/8" D
(from the backplate)
(10.79 H x 8.25 W x 2.99 cm)
MS-95 with key reset
option: 6.25" H x 3.25" W x 2.0" D (from
backplate) with Cat 60 Key
(15.88 H x 8.25 W x 5.08 D cm)
Surface Backbox
P/N: 28762: 4.625" H x 3.25" W 2.375" D
tapped for 3/4" (1.9 cm) conduit
(11.75 H x 8.25 W x 6.03 D cm)
Surface Backbox
P/N: 71961: 6.25" H x 3.0" W x 3.25" D
(15.88 H x 7.6 W x 8.25 D cm)
Ordering Information
Part Number Description
MS-95 Analog addressable manual pull station
MS-95T Analog addressable manual pull station
with terminals
30653 Double action option
30653-01 Key reset option
30653-02 Key reset/double action option
27060 Breakglass rod
28762 Surface backbox
50397G Weather proof gasket for MS-95 station
72198 NYC manual station backplate with
1" (2.54 cm) white stripe
71961 Backbox, surface for key reset options
