HM700A1000
15 33-00118—01
Fig. 20. Humidifier components.
Steam Outlet
Condensate Return
Fill Cup
Drain ValveDrain Canal
Fill Valve
Cylinder
Cylinder Plug
High Water Sensor
Plug
On/Off/Drain Switch
Control Board
Power Relay
High Voltage
Terminal Block
Transformer
Control Terminal
Strip
