Operation and maintenance manual HON HSV086 25
Slide filler block 01 over connection rod 04 and fit retainer set 02 (with new O-ring
21).
Unscrew the screws from the seat of valve 15.
Remove valve seat 15.
Check valve seat 15 for damage to the top sealing edge.
Replace O-ring 32 and slowly and carefully mount valve seat 15 in the body of
valve 16.
Slowly lower cover 09 with valve 12 hanging underneath it into body 16.
Fit screw connection 28.
Mount the complete SVC086 on cover 09 by means of screw connection 47.
Connect impulse line of the pressure converter.
Recommission the line (if no other maintenance work is necessary).
Remark
Check the threshold values of the HON HSV after each maintenance!
CAUTION !!!
Always carry out an operational and tightness test
after maintenance work!
