Engine Oil
20 www.honeywellgenerators.com HW1000i / HW2000i Inverter Generator Owner’s Manual
Engine Oil
6.
Place the oil pan, or other container suitable for hold-
ing engine oil, in front of the generator.
7. Remove the oil fill cap.
8. Attach the oil drain pipe (do not over tighten) and tilt
the generator allowing the oil to completely drain into
the oil pan.
9. Return the unit to the upright position.
10. Remove the oil drain pipe.
11. Using a clean cloth, wipe around the drain plug area
to remove any dirt and debris.
12. Fill the oil fill container (included) with the appropriate
amount and type of new (unused) oil. (See Figure 17
for recommended oil type.)
13. Slowly pour oil into the oil fill hole. DO NOT OVER-
FILL.
14. Check the oil level is up to the innermost thread of the
crankcase.
FIGURE 23: Oil Drain Pan
FIGURE 24: Oil Fill Cap Removal
FIGURE 25: Drain Oil (HW2000i Model)
Generator is heavy! Obtain assistance to lift the
generator to avoid back or other bodily injury.
HW1000i HW2000i
Oil Capacity [qt / ml]
0.26 / 250 0.48 / 450
TABLE 5. Engine Oil Capacity
FIGURE 26: Adding Engine Oil
FIGURE 27: Oil Fill Measurement
