Wiring Diagram
• If the air conditioner is provided with an interconnection cord, the wiring of the
indoor unit is connected in the factory, there is no need of connection.
• If the interconnection cord is not provided, connection is needed in accordance
with the wiring diagram.
NOTE:
• This manual usually includes the wiring mode for the different kind of A/C. We
cannot exclude the possibility that some special type of wiring diagrams are not
included.
• The diagrams are for reference only. If the entity is different with this wiring
diagram, please refer to the detailed wiring diagram adhered on the unit.
INSTALLATION: INDOOR UNIT
13
Constant Speed Variable Speed
Connector
If there is a connector, connect it
directly.
5 4 3 2(N) 1(L)
5 4 3 2(N) 1(L)
N SL
N SLoL
To Next Page
