Honeywell Maxon HMA11 User Manual

GAS ELECTRO-MECHANICAL VALVES
E - m - 05/22 5 32M-95001—04
Agency approvals and certifications
General Purpose Valves
SMA11, SMM11, CMA11,
CMM11, SMA21, SMM21,
CMA21, HMA11
Non-Incendive/Non-Sparking Valves
SMA12, SMM12, SMA22, CMA22,
CMA12, CMM12, SMM22, CMM22
Standards Markings Standards Markings
FM Approvals
FM 7400
FM 7400
FM 3600
FM 3611
FM 3810
Class I, Div. 2, Groups ABCD
Class II, Div. 2, Groups FG
Class III, Div. 2
T4 (AC) = 60°C
T3 (DC, sizes 3/4” - 1-1/2”) = 60°C
T3C (DC, sizes 2”-6”) = 60°C
IECEx
Not Applicable
IEC 60079-0
IEC 60079-15
IEC 60079-31
Ex nA nC IIC T4A (AC), T3 (DC), Gc
Ex tc IIIC T135°C Dc IP65
-29°C < Ta < 60°C IP65
IECEx FMG 11.0032X
UL UL 429
Not Applicable Not Applicable
CSA
CSA 6.5
CSA 22.2 No. 139
CSA 6.5
CSA 22.2 No. 139
CSA 22.2 No. 0
CSA 22.2 No. 0.4
CSA 22.2 No. 25
CSA 22.2 No. 94
CSA 22.2 No. 142
CSA 22.2 No. 213
Class I, Div. 2, Groups ABCD
Class II, Div. 2, Groups FG
Class III
T4 = 60°C
T3C = 60°C
United Kingdom
GAR, LVD
Compliance
BSEN 161
BSEN13774
TP 6.16
Not Applicable
European GAR, LVD,
EMC Compliance
BSEN 161
BSEN13774
TP 6.16
Not Applicable Not Applicable
United Kingdom
PED Compliance
Not Applicable Not Applicable
European PED
Compliance
Not Applicable Not Applicable
SIL IEC 61508
Not
Applicable
IEC 61508
Not Applicable
KTL Approvals
Not Applicable Not Applicable
MA12: 12-KB4BO-0057
MM12: 13-KB4BO-0419
MA22: 16-KA4BO-0027X
MM22: 16-K4BO-0028X
AGA Certifications
AS 4629
(CLASS 1)
Not
Applicable
AS 4629
Not Applicable
Chinese Approvals
Not Applicable
GB 3836.1,
GB 3836.8,
GB 12476.1,
GB 12476.5
Ex nA nC IIC T4(AC),
T3(DC) Gc,
Ex tD A22 IP65 T135°C
Gas Appliance Regulation (EU) 2016/426 (Does not include 400HMA11 or 600HMA11 valves)
Low Voltage Directive (2014/35/EU)
EMC Directive (2014/30/EU)
Pressure Equipment Directive (2014/68/EU) up to DN100
Class A, Group 2 per EN 161
FM 7400
FM 7400
FM 3600
FM 3611
FM 3810
