Honeywell MK VIII User Manual

EGPWS LINE MAINTENANCE MANUAL
CAGE CODE: 97896 SCALE: NONE SIZE: A DWG NO.: 060-4199-180 REV: G SHEET 13 of 68
MODEL
CALLOUT DESCRIPTION
V VI VII VIII XXII
500 TONE Provides 2 second 960 Hz tone at descent below 500
feet
•
#
•
# #
SMART “FIVE HUNDRED” At descent below 500 feet (only) during non-precision
approach
• • • • •
“FIVE HUNDRED” Above field callout within 5 nm of a runway in the
database
#
•
#
•
#
“FIVE HUNDRED ABOVE” Above field callout within 5 nm of a runway in the
database
#
•
#
•
#
“FOUR HUNDRED” At descent below 400 feet
• • • •
#
“THREE HUNDRED” At descent below 300 feet
• • • •
#
“TWO HUNDRED” At descent below 200 feet
• • • • •
“ONE HUNDRED SIXTY” At descent below 160 feet
# # # #
•
“ONE HUNDRED FIFTY” At descent below 150 feet
# # # #
•
“ONE HUNDRED FORTY” At descent below 140 feet
# # # #
•
“ONE HUNDRED THIRTY” At descent below 130 feet
# # # #
•
“ONE HUNDRED TWENTY” At descent below 120 feet
# # # #
•
“ONE HUNDRED TEN” At descent below 110 feet
# # # #
•
“ONE HUNDRED” At descent below 100 feet
• • • • •
100 TONE Provides 2 second 700 Hz tone at descent below 100
feet
•
#
•
# #
“EIGHTY” At descent below 80 feet
•
#
•
#
•
“SIXTY” At descent below 60 feet
•
#
•
#
•
“FIFTY” At descent below 50 feet
• • • • •
“FOURTY” At descent below 40 feet
• • • • •
“THIRTY FIVE” At descent below 35 feet
•
#
•
# #
35 TONE Provides 1 second 1400 Hz tone at descent below 35
feet
•
#
•
# #
“THIRTY” At descent below 30 feet
• • • • •
“TWENTY” At descent below 20 feet
• • • • •
20 TONE Provides 1/2 second 2800 Hz tone at descent below
20 feet
•
#
•
# #
“FIFTEEN” At descent below 15 feet
•
#
•
# #
“TEN“ At descent below 10 feet
• • • • •
“FIVE” At descent below 5 feet
•
#
•
# #
# Not currently identified in any menu option for the model indicated.
