EGPWS LINE MAINTENANCE MANUAL
CAGE CODE: 97896 SCALE: NONE SIZE: A DWG NO.: 060-4199-180 REV: G SHEET 35 of 68
THE FOLLOWING INFORMATION IS GIVEN IN THE LEVEL 3 SELF-TEST:
“GPS ALTITUDE REF WGS84 SELECTED”
“AUTOROTATION CALLOUT X SELECTED” (MK XXII)
“NORMAL POPUP RANGE X SELECTED” (MK XXII)
“LOW ALTITUDE POPUP RANGE X SELECTED” (MK XXII)
“MODE 6B ALWAYS ON SELECTED” (MK XXII)
“NORMAL TERRAIN WITH AIRSPEED SELECTED” (MK XXII)
“LOW ALTITUDE WITH AIRSPEED SELECTED” (MK XXII)
“SAR LOW ALTITUDE SELECTED” (MK XXII)
“AUDIO INHIBIT TIME X” (MK XXII)
“INHIBIT ALL EXCEPT MINIMUMS TYPE CALLOUT AND 100 CALLOUT SELECTED” (MK XXII)
“INHIBIT ALL EXCEPT MINIMUMS TYPE CALLOUT SELECTED” (MK XXII)
“INHIBIT TOO LOW GEAR SELECTED” (MK XXII)
“INHIBIT RUNWAY CALLOUTS 50 AND BELOW SELECTED” (MK XXII)
“ALTERATE DECISION HEIGHT SELECTED” (MK XXII)
* “RUNWAY AWARENESS ENABLE SET” OR “RUNWAY AWARENESS ENABLED”
* “APPROACH MONITOR ENABLED”
* “FLAPS MONITOR ENABLED”
* “ALTIMETER MONITOR ENABLED”
* “LONG LANDING ENABLED”
* “AIRSPEED LOW INHIBITED”
*Ensure that none
of these maintenance messages above or listed in Appendix C through H of this document are
enunciated during the Level 3 Self-Test or terrain display range changes (respectively) unless these optional
functions are activated for your aircraft. See the applicable aircraft AFMS and/or Instructions for Continued
Airworthiness (ICAW) documentation to determine if these functions are activated.
