EGPWS LINE MAINTENANCE MANUAL
CAGE CODE: 97896 SCALE: NONE SIZE: A DWG NO.: 060-4199-180 REV: G SHEET 56 of 68
An example CUW command/data string, its definition, and the corresponding CWR list is provided below.
CUW command/data string:
CFG > CUW 0/15 2 3 2 0 0 3 95 1 0 0 0 0 0 0 0/
Above Configuration defined:
Category 1 Aircraft/Mode Type: 2
Category 2 Air Data Source: 3
Category 3 Position Source: 2
Category 4 Altitude Callouts Menu: 0 (All callouts)
Category 5 Audio Menu: 0 (Basic menu)
Category 6 Display Configuration: 3
Category 7 Select Group #1 Options: 95
Steep Approach Enabled: True
TA&D Alternate Pop-Up: False (Pop-Up on Caution or Warning)
Peaks Mode Enable: True
Obstacle Awareness Enabled: True
Bank Angle Enable: True
Flap Reversal: True
GPS Altitude Reference: MSL (required for internal GPS source, Cat 3 ID 2)
Category 8 Radio Altitude Input Select: 1
Category 9 Navigation Input Select: 0
Category 10 Attitude Input Select: 0
Category 11 Heading Input Select: 0
Category 12 Windshear Select type: 0
Category 13 Discrete I/O Type Select: 0
Category 14 Audio output Level Select: 0 (Equiv. to MK VI GPWS output level)
Category 15 Undefined 0
CWR list: (based on above configuration)
CFG > CMR
CONFIGURATION MODULE:
Format Version: 0
Category 1 ID: 2
Category 2 ID: 3
Category 3 ID: 2
Category 4 ID: 0
Category 5 ID: 0
Category 6 ID: 3
Category 7 ID: 95
Category 8 ID: 1
Category 9 ID: 0
Category 10 ID: 0
Category 11 ID: 0
Category 12 ID: 0
Category 13 ID: 0
Category 14 ID: 0
Category 15 ID: 0
CRC: 1565805624
