Honeywell MM14CCS User Manual

REMOTE CONTROL
The functions work the same as the portable air conditioner's Touch Screen Control Panel.
All key functions can be accessed from the remote control.
USE & OPERATION (CONTINUED)
•
•
•
Used for adjusting the timer and temperature.
When ▼ or ▲ key is pressed in cool mode, the
set temperature is displayed and may be
adjusted. After 10 seconds the display will
revert back to room temperature.
Timer setting is available from 1-24 hours by
pressing the key ▼ or ▲
Press this button to change the operation mode
in the order of:
ON / OFF
• HIGH • MEDIUM • LOW
In running mode: Auto switch off
In stand-by mode: Auto switch on
Press ▼ or ▲ button to adjust the
time setting for 1 hour intervals.
Temperature / Timer Set
Mode Control
Power Control
Fan Speed Control
Timer Control
Battery Installation: Remove the cover on the back of the remote control and insert two AAA batteries
with + and - pointing in the proper direction according to the polarity markings.
Use only two AAA or IEC R03 1.5V batteries.
Remove the batteries if the remote control is not in use for a month or longer.
All batteries should be replaced at the same time, do not mix with old batteries.
Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium) batteries.
Properly dispose of used batteries.
•
•
•
•
•
•
Note:
Caution:
Cool Dehumidify
Fan
EN 7

Honeywell MM14CCS Specifications

General

Type	Monobloc mobile air conditioner
Timer	Yes
Timer type	Digital
Hose length	1.2 m
Noise level	53 dB
Hose diameter	127 mm
Refrigerating medium	R410A
Cooling capacity (max)	14000 BTU/h
Dehumidifying capacity	1.875 l/h
Timer duration (maximum)	24 h
Air conditioner functions	Cooling, Dehumidifying, Fan
Suitable for room area up to	46.5 m²
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	-
Display type	LCD
Product color	Black, Silver
Connected load	1500 W
Hourly energy consumption (heating)	- kWh

Weight and Dimensions

Depth	170.18 mm
Width	391.16 mm
Height	635 mm
