Honeywell MN12CES User Manual

Note :
Do not place the remote control in direct sunlight.
Timer Control
Temperature / Timer Set
Mode Control
Cool
Dehumidify
Fan
In running mode:
Auto switch off
In stand-by mode:
Auto switch on
Press “ ▼ “ or “▲“ button
to adjust the time
setting for 1 hour intervals.
Control
• Used for adjusting the timer
and temperature.
• The default display is room
temperature.
• When “ ▼ “ or “▲“ key is
pressed in cool mode, the set
temperature is displayed and
may be adjusted. After 10
seconds the display will revert
back to room temperature.
• Timer setting is available from
1-24 hours by pressing the
key “ ▼ “ or “▲“
Press this button to change the
operation mode in the order of:
Remote Control
The functions work the same as the portable air conditioner’s touch
controls. All key functions can be accessed from the remote control.
11
USE & OPERATION
Power Control
ON / OFF
Fan Speed Control
• HIGH • MEDIUM • LOW

Honeywell MN12CES Specifications

General

Type	Split mobile air conditioner
Air filter	Yes
Hose length	1.2 m
Noise level	53 dB
Hose diameter	127 mm
Number of speeds	3
Refrigerating medium	R410A
Cooling capacity (max)	12000 BTU/h
Dehumidifying capacity	31 l/h
Air conditioner functions	Cooling, Dehumidifying
Cooling temperature range	16 - 31 °C
Suitable for room area up to	45 m²
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	-
Display type	LED
Product color	Black
AC input voltage	220 - 240 V
Hourly energy consumption (cooling)	- kWh

Weight and Dimensions

Depth	386 mm
Width	459 mm
Height	744 mm
Weight	33792 g
