When there is excess water condensation inside the unit, the air conditioner stops running and
shows a warning light (refer to page 10). This warning light indicates that the water condensation
needs to be drained using the following procedures:
WATER CONDENSATION DRAINAGE
14
Continuous Draining
While using the unit in dehumidifier mode, continuous drainage is
recommended.
Upper
Drain Plug
Unplug the unit from power source.
Place a shallow pan under the lower drain plug. See diagram.
Remove the lower drain plug.
Water will drain out and collect in the shallow pan.
After the water is drained, replace the lower drain plug firmly.
You can now turn on the unit.
Manual Draining
Water Condensation Drainage
1.
2.
3.
4.
5.
6.
Unplug the unit from the power source.
Remove the upper drain plug. While doing this operation some
residual water may spill so please have a pan to collect the water.
Connect the drain connector to a ¾” hose (not included).
See diagram.
The water can be continuously drained through the hose into a
floor drain or bucket.
You can now turn on the unit.
1.
2.
3.
4.
5.
Lower
Drain Plug
Water Drain Pipe
Water may need to be drained in high humidity areas
Shallow Pan
(Not included)

Honeywell MN12CES Specifications

General

Type	Split mobile air conditioner
Air filter	Yes
Hose length	1.2 m
Noise level	53 dB
Hose diameter	127 mm
Number of speeds	3
Refrigerating medium	R410A
Cooling capacity (max)	12000 BTU/h
Dehumidifying capacity	31 l/h
Air conditioner functions	Cooling, Dehumidifying
Cooling temperature range	16 - 31 °C
Suitable for room area up to	45 m²
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	-
Display type	LED
Product color	Black
AC input voltage	220 - 240 V
Hourly energy consumption (cooling)	- kWh

Weight and Dimensions

Depth	386 mm
Width	459 mm
Height	744 mm
Weight	33792 g
