VRN PRESSURE INDEPENDENT CONTROL VALVES AND ACTUATORS
3 38-00032—01
Example part number: VRN2A001.00PA+MVN613A0000+C1
* Only compatible with valves 1-1/4” or smaller.
Table 1. VRN Model Selection.
Model Selection: Pressure Independent Control Valve
Actuator Fail Position Accessories
Valve
Fitting
Body/Flow Type
Size
Max flow rate
Trim
Profile
VR - Pressure Independent Control Valve MVN613A0000* Leave blank = Fail in place C1 - 1 meter cable
N- Female NPT threaded MVN643A0000* 3R - NEMA
Enclosure
2- 2 way MVN713A0000*
MN6105A1011
MN6105A1201
MN7505A2001
A - 1/2 (DN15)
B - 3/4 (DN20)
C - 1 (DN25)
D - 1-1/4 (DN32)
E - 1-1/2 (DN40)
F - 2 (DN50)
G - 2-1/2 (DN65)
H - 3 (DN80)
MN7505A2209
MS7505A2030
FSO = Fail Safe Open
FSC = Fail Safe Closed
MS7505A2130
MS8105A1030
MS8105A1130
MS4105A1030
MS4105A1130
xxx.xx - Max flow rate designator
See Table 4.
P - Plated Brass
S - Stainless Steel
A - Standard Base
X - MN/MS DCA
Actuator Bracket
VR N 2 A 001.00 P A + MVN613A0000 + + C1
Table 2. Actuator Control Description.
Actuator Control
MVN613A0000
Floating, Two-position (SPDT or SPST) (90 sec. timing), 24 V, Fail in Place
MVN643A0000
Floating, Two-position (SPDT) Fast Acting (30 sec. timing), 24 V, Fail in Place
MVN713A0000
Modulating, 24 V, Fail in Place
MN6105A1011 Floating, Two-position (SPDT), 24 V, Fail in Place
MN6105A1201 Floating, Two-Position (SPDT), 24 V, Fail in Place with end switches
MN7505A2001 Modulating, 24 V, Fail in Place
MN7505A2209 Modulating, 24 V, Fail in Place with end switches
MS7505A2030 Modulating, Floating, Two-position (SPDT), 24 V, Fail Safe
MS7505A2130 Modulating, Floating, Two-Position (SPDT), 24 V, Fail Safe with end switches
MS8105A1030 Two-Position (SPST), 24 V, Fail Safe
MS8105A1130 Two-Position (SPST), 24 V, Fail Safe with end switches
MS4105A1030 Two-Position (SPST), 120 V, Fail Safe
MS4105A1130 Two-Position (SPST), 120 V, Fail Safe with end switches
