VRN PRESSURE INDEPENDENT CONTROL VALVES AND ACTUATORS
7 38-00032—01
Fig. 2. Dimensions of valves used with MN/MS actuators; see Table 6.
Actuator not shown. See Figures 4 and 5 for MN/MS actuator dimensions.
a
Long shaft supplied with “Zelix” direct coupled spring return actuators; short shaft supplied with MN series stay-in-place
DCAs.
b
Do not use stainless steel replacement stem assemblies in valves with plated brass trim; galvanic reactions may occur.
c
Actuator dimensions fall within the envelope of the handle and mounting bracket. See actuator literature for detailed
dimensions.
Table 6. Dimensions of valves used with MN/MS actuators; see Fig. 2.
See Figures 4 and 5 for MN/MS actuator dimensions.
Model Pipe Size Flow, gpm (m
3
/h) Dimensions
c
in in. (mm)
Weight
lb. (kg)
Service Replacement
PartsNPT in. S.I. metric Min. Rating Max. Rating Full Port A B C D E Fz
a
Fs
a
VRN2A
1/2 DN15
1.0 (0.23)
7.0 (1.6)
5.71
(145)
5.43
(138)
8.87
(225)
2.32
(59)
2.5 (64)
10.02
(255)
8.77
(223)
2.5 (1.1)
Stem: 5112-19
5112-22 (SSb);
Regulator:
8615-100 for 1-3 gpm;
8615-101 for 4-10 gpm
VRN2B
3/4 DN20 9.0 (2.0) 10 (2.3)
8.94
(227)
VRN2C
1DN25
15.0 (3.4)
5.83
(148)
20 (4.5) 20 (4.5)
9.65
(245)
6.10
(155)
11.44
(291)
2.41
(61)
10.68
(271)
9.43
(240)
7.1 (3.2)
Stem: 5112-20
5112-23 (SSb);
Regulator:
8615-102
VRN2D
1–1/4 DN32
10 (2.3)
30 (6.8) 35 (7.9)
8.98
(228)
(213)
11.10
(282)
VRN2E
1–1/2 DN40
35 (7.9)
8.80
(224)
11.01
(280)
40 (9.1) 85 (19.3) 95 (21.6)
10.66
(271)
6.95
(177)
12.84
(326)
2.93
(74)
11.55
(293)
10.30
(262)
13.7 (6.2)
Stem: 5112-21
5112-24 (SSb);
Regulator:
8615-031
VRN2F
2DN50
25 (5.7)
75 (17.0)
10.97
(279)
13.00
(330)
VRN2G
2–1/2 DN65
85 (19.3) 95 (21.6)
11.42
(290)
13.23
(336)
VRN2H
3DN80
11.80
(300)
13.41
(341)
M35993
F
B
A
C
D
E
