4
2. The Window Brackets are approximatley 19.7" (50 cm) each, allowing you to install to windows
and balcony doors of different heights or width.
Adjustable Knobs
INSTALLATION (CONTINUED)
To install the window bracket to the window frame, you need to adjust the height or width of the
window bracket by extending the length according to the height or width of the window. When the
length is set, tighten the Adjustable Knobs (preinstalled on the window bracket) to ensure the window
bracket is secured in the desired position. Use one or all two pieces of window bracket as needed.
3. Connect the Exhaust Hose to the Exhaust Hose Connector on back of the unit. Slide-in the
Exhaust Hose Connector. Press the button to lock the Exhaust Hose Connector in place.
Note: After setting the window bracket to the size of your window, please remove it from the window
and follow the instructions below.
EN
19.7"
(50 cm)
1 part
19.7" (50 cm) to
38.2" (97 cm)
2 parts
47.2" (1.2 m)
3 parts
To Next Page
