6
INSTALLATION (CONTINUED)
IMPORTANT: Do not replace or lengthen the Exhaust Hose as this could cause the unit to
malfunction.
The supplied Hose has a diameter of 5.5" (14 cm) and can be extended from 12" to 47" (30 cm to
120 cm).
Do not bend (to the extent shown below) the Hose. A bent Hose will block exhaust air and cause
the unit to malfunction or shut-off.
Make sure the back of the unit is at least 20" (50 cm) away from the wall. Do not place the unit in
front of curtains or drapes as this could obstruct the airflow.
•
•
•
WARNING: Any warranties included with this product will be voided if an extra extension Hose is
added to the originally provided installation kit or if the installation is performed differently than the
manufacturer's instructions, without proper consultation. Please contact Customer Support for help
with installation procedures if needed.
NOT RECOMMENDED RECOMMENDED
20" (50 cm)
MAX. 14" (36 cm)
EN
MAX. 40" (102 cm)
