4
2. There are 3 varying lengths to the window bracket, 19.7 inches (50 cm), 38.2 inches (97 cm)
and 59.1 inches (1.5 m). For sizes smaller than the listed size please bring the panel to your
local hardware shop to be cut to the length you need. The bracket can be installed horizontally or
vertically.
Adjustable Knobs
INSTALLATION (CONTINUED)
To install the window bracket to the window frame, you need to adjust the height or width of the
window bracket by extending the length according to the height or width of the window. When the
length is set, tighten the Adjustable Knobs (preinstalled on the window bracket) to ensure the window
bracket is secured in the desired position. Use one or all two pieces of window bracket as needed.
3. Connect the Exhaust Hose to the Exhaust Hose Connector on back of the unit. Slide in the
Exhaust Hose Connector. Press the button to lock the Exhaust Hose Connector in place.
Note: After setting the window bracket to the size of your window, please remove it from the window
and follow the instructions below.
EN
19.7"
(50 cm)
1 part
19.7" (50 cm) to
38.2" (97 cm)
2 parts
59.1" (1.5 m)
3 parts
