INSTALLATION
It is important that the installation instructions below are followed for successful installation of this
Portable Air Conditioner. Please call Customer Support if you have any difficulties or queries
regarding these installation procedures.
Installation Kit:
Installation Steps:
Exhaust Hose Connector, Exhaust Hose and window bracket panel adapter are pre-assembled
inside the package.
1.
1. Window Bracket Kit (1 Set) 6. Butterfly Screws (2 Pieces)
2. Window Bracket Panel Adapter (1 Piece) 7. Insulation Tape (gray, adhesive) (1 Piece)
3. Exhaust Hose Connector (1 Piece) 8. Insulation Tape (black, adhesive) (1 Piece)
4. Hole Cover (1 Piece) 9. Foam Insulation Pads (non-adhesive) (2 Pieces)
5. Exhaust Hose (1 Piece)
1 3
x1
x1 x1
2
Exhaust Hose:
Length: 12" to 47" (30 cm to 120 cm)
5 6
x1 x2
4
x1
7
x1 x1
8 9
x2
