Chapter 3 — How to Set Up Your Printer
MP Compact4 Mark III User Guide 9
Interface Connection
The printer can be connected to the host via USB, serial, wired Ethernet, or
optional wireless interfaces. The printer will automatically connect to the first
port that delivers valid data. Once established, the printer’s power must be
cycled “off” and “on” to change an interface connection.
1 LAN (RJ-45 wired Ethernet)
2 USB
3 Wireless antenna connector (optional)
4 COM1 (RJ-45)
Serial Connections (COM1)
The serial interface supports RS-232C communications via an RJ45 connector.
The following list of serial port settings is menu selectable (via host software/
driver) and must match the host computer’s serial port settings: Baud Rate
(Default 9600 bps) > Word Length (Default 8 bits).
USB Connection (USB)
The USB interface is supported in Windows 95 and greater. Depending upon
the operating system of your host computer, installation may differ slightly.
Wired and Optional Wireless
For setup information on wired and optional wireless connections, see “Set Up
Wireless” on page 43.
Before connecting power or interface cables to the printer, ensure the power on/
off switch is in the “off” position.
