MPD Operating Manual
25
8. Replacement Parts
8.1 MPD Catalytic Bead and IR Replacement Sensor Cartridges
Sensor
Type
Target Gas
Cartridge
Part No
Maximum
Range
Selectable
Range
Increment
Default
Range
MPD-IC1
Carbon
Dioxide
1226-0301 5.00 %Vol 1.00 to 5.00 %Vol 1.00 %Vol 5.00 %Vol
MPD-IV1 Methane 1226-0299
5.00 %Vol or
0-100%LEL
1.00 to 5.00 %Vol
or 0-100%LEL
n/a 0-100%LEL
MPD-IF1 Flammables 1226-0300 100 %LEL 20 to 100 %LEL 10 %LEL 100 %LEL
MPD-CB1 Flammables 1226A0359 100 %LEL 20 to 100 %LEL 10 %LEL 100 %LEL
NOTe:
When ordering replacement MPD sensor cartridges, the replacement
cartridge MUST be the same type as factory configured. Substituting a
different cartridge will void agency certification.
8.2 Terminal Housings
NOTe
When ordering replacements, always quote the complete part number.
Where a part number is not listed or known, state type, material, cable
entry size and other relevant details.
Part Number Description Cable Entry Thread
2441-0022 UL/CSA Aluminum Junction Box (2 entries) 3/4 NPT
2110B2103 UL/CSA Stainless Steel Junction Box (2 entries) 3/4 NPT
00780-A0100 ATEX/IEC Junction Box (3) M20, (1) M25 entries. M20/M25
8.3 Maintenance Spares
When ordering replacements, always quote the complete part number.
Part Number Description
1226A0354 Remote Gassing Port
02000-A-1642 Collecting Cone
1226A0411 Sample Flow Adaptor
02000A1640 Weatherproof Cap
S3KDMK Duct Adaptor Kit
1226A0382 MPD Duct Interface Adaptor (S3KDMK req’d)
SPXCDWP Weatherproof Housing
