Honeywell MS 10 Series User Manual

MSXX10, MSXX20 SERIES
3 63-2607—26
Timing (At Rated Torque and Voltage):
Drive Open (typical):
Floating, Modulating Models: 90 seconds.
Floating, Modulating Models: 60 seconds.
Two-Position Models: 40 seconds ±10 seconds.
Spring Close: <25 seconds.
Fig. 1. Dimensional drawing of actuator in in. (mm).
60 second models:
MS7510A2016
MS7510A2214
MS7520A2015
MS7520A2213
Table 3. Electrical Ratings*.
* Floating/Modulating 60 sec models
88 lb-in. (10 Nm) 18 VA Driving
175 lb-in. (20 Nm) 22 VA Driving
24 VAC +- 20%
Stroke: 95° ±3°, mechanically limited. Approvals: See Table 4.
9-3/4
(247)
1-9/16
(40)
2-1/2
(64)
MIN.
3 (76)
MIN.
3 (76)
MIN.
FROM
SHAFT
END
6-1/8
(156)
1-9/16
(40)
1-9/16
(40)
3-15/16 (100)
2-15/16 (75)
1/4 (6)
M28939
144 (3658)
1
1
CABLE AND STRAIN RELIEF
ON SELECT MODELS ONLY.
Table 2. Model Selection.
a
Model manufactured for sale in the United States.
b
Model manufactured for sale in Europe.
c
Cables available on 75 and 81 Series only.
M Electrical Motor
S Fail Safe Function (Spring Return)
31 24 Vac communicating (Sylk Enabled)
41 120 Vac Two-Position Control; Reversible Mount
71 24 Vac Modulating Control; Reversible Mount
75 24 Vac Modulating and Floating Control; Reversible Mount
81 24 Vac Two-Position Control; Reversible Mount
10 88 lb-in. (10 Nm)
20 175 lb-in. (20 Nm)
A
a
Standard U.S. Model
B
b
Standard European Model
E
b
Selectable control signal; Adjustable zero and span;
Includes service and auto-adapt modes
H
a
J Sylk Enabled
W
c
Standard U.S. Model with Cable
1 No Feedback
2 Voltage Feedback Signal
0 No End Switches
2 Two End Switches
XX System Controlled Numbers
M S 75 20 A 2 0 XX
Model(s)
Power Input Power Consumption (VA)
Voltage Frequency
44 lb-in. (5 Nm) 88 lb-in. (10 Nm) 175 lb-in. (20 Nm)
Driving Holding Driving Holding Driving Holding
Floating, Modulating 24 Vac ±20% (Class 2), 24 Vdc 50/60 Hz. 13 5 14 5 16 5
Two-Position, Low-voltage 24 Vac ±20% (Class 2), 24 Vdc 50/60 Hz. 25 8 30 8 40 8
Two-Position, Line-voltage 100-250 Vac 50/60 Hz. 45 13 45 13 60 13
