Table 10.1 :
Minitrend QX - Spares
1 51453012-502 QX Processor Board Assy
2 51453006-501
51453006-502
51453006-503
QX Analogue Input 4CH Assy
QX Analogue Input 6CH Assy
QX Analogue Input 8CH Assy
2 51453027-501
51453027-502
QX Analogue Output 2CH Assy
QX Analogue Output 4CH Assy
2 50001017-502 QX Pulse Input 4CH Assy
3 51453009-501 QX Mother Board Assy
4 51453018-501
51453018-502
QX Digital I/O 8CH Assy
QX Digital I/O 16CH Assy
4 51453021-501
51453021-502
QX Relay Alarm 4CH Assy
QX Relay Alarm 8CH Assy
5 51453015-501
51453015-502
51453015-503
QX Power Supply AC Mains
QX Power Supply AC/TX
QX Power Supply 20V/55VDC/20-
30VAC
7 50013945-501
50013945-502
QX Bezel/Touch Screen and Std Nema
3/IP54 Door Assy
QX Bezel/Touch Screen and Nema 4X/
IP66 Door Assy
Includes Bezel, Touch
Screen and Door Assy
9 50003508-501 QX Nema 4X/IP66 Door
10 50009118-501 QX Std Nema 3/IP54 Door
16 50006685-502
50006685-502
QX Bezel/Touch Screen/Display As-
sembly NEMA 4X/IP66
QX Bezel/Touch Screen/Display As-
sembly NEMA 3/IP54
Includes Bezel Touch
Screen Assy, Door,
Display, Speaker, In-
verter, cables and
Mounting Bracket
19 51453076-501 QX 5.5” Display
23 50001782-501 QX / SX Speaker
25 50016276-501 QX Vutronik Adaptor Assy Not shown
24 51453071-501 QX Case and Back Plate Assy
27 51453077-501 QX Inverter and Cable Assy
28 50006787-501 QX / SX Battery (Kit of 5)
