Page 4 Programming manual AM-1000
NOTIFIER ITALIA Doc. M-145.2-AM1000-ENG Rev A.1 AM1000_manu
D
D
E
E
S
S
C
C
R
R
I
I
P
P
T
T
I
I
O
O
N
N
U
U
S
S
E
E
R
R
I
I
N
N
T
T
E
E
R
R
F
F
A
A
C
C
E
E
Functions List
Functions EN.54 Level Manufactured Default Password
Visualisation of alarms and troubles Level 1 no one
Visualisation of cancelled indication Level 1 no one
Identification of alarms and troubles Level 1 no one
Settino of delay (dedicated push-button) Level 1 no one
Visualisation of excluded zones/points Level 1 no one
Exclusion menù Level 2 22222
Test menù Level 2 22222
Utilità menù Level 3 33333
Programmino menù Level 4 44444 + internal Jumper (see note)
%
Note. The entry in the non-volatile memory is subject to the position of the jumper J1 (hardware key) on
the back of the display.
Description of the keyboard function for the isnertion of the data in the
programming files:
With the indicators 34it is possible to move to the adjacent files.
With the indicators 56it is possible to visualize the fields in the files (the selected field appears with the
REVERSE prompt).
If the file provides for an index, we have the first two function buttons allowing the flowing.
The selected field can be changed using the editing form with the return key
.
According to the type of data we have different editing:
- strings:4 new functioning key are displayed (F1 capital/small selection, F2 letters/numbers/symbols
selection, F3 insertion, F4 delete) with the indicators 56 it is possible to select the type for the current
position, with 34it is possible to move inside the file.
- numbers that can be modified : with 56it is possible to select the current digit, with 34it is possible to
select the position to be modified (trying to insert a value outside the admitted interval we obtain the
visualisation of the limits).
- numbers that cannot be modified: with 56it is possible to see in sequential way all the values.
- labels: with 56it is possible to see in sequential way all the selectable labels.
- address : simultaneous editing of two numerical fields.
At the end of the editing with the return key
it is possible to accept the new value or with the escape key
it is possible to leave the changes.
To leave the file system we use the escape key.
