2 VEA Product Guide — P/N LS10215-000NF-E:A 07/24/2018
References
Introduction
The VEA-040-Axx-NTF models have implemented an interface to the FACP over the SLC loop. An interface module mounted to the inside of the
VEA door provides the SLC interface for the detector.
The SLC detector does not have VESDAnet capability as the networking is provided by the SLC loop.
Specifications specific to SLC detectors
• Power drawn from the SLC loop: 30mA
• Event reporting is achieved via event logs
NOTE: This model doesn’t support the expansion STAX
Ordering Information
VESDA-E VEA-040-Axx Detector capable of interfacing to NOTIFIER panels:
• VEA-040-A00-NTF: NOTIFIER Intelligent VESDA-E VEA-40 point with LEDs
• VEA-040-A10-NTF: NOTIFIER Intelligent VESDA-E VEA-40 point with 3.5" Display
Compatibility with FACP
VEA-040-Axx-NTF is compatible with the following NOTIFIER FACPs:
• NFS2-3030
• NFS2-640
• NFS-320
Installation
VEA is an addressable Aspirating Smoke Detector (ASD) with 40 addressable microbore tubes. VEA is configured as an ASD in a 5-address space
providing the Alert and Action pre-alarms; and the Fire-1 and Fire-2 alarm conditions. Each of the 40 microbore tube air sampling points are to be
configured as a photo detector on the SLC loop. Each VEA will occupy 45 consecutive addresses on the SLC loop.
Document Id Description
27034 VESDA-E VEA-040-A00 Product Guide
27035 VESDA-E VEA-040-A10 Product Guide
CAUTION: DO NOT CONNECT ANY OTHER DEVICE TO THE SPARE VESDANET PORT ON THE VEA-040-Axx-NTF.
