Installing the PRO4200 Two Reader Module
Set Up
PRO4200 Two-reader module User Guide, Document 800-25698V1 13
Set Up
Table 1: PRO4200 IN Module Jumper Setting
Jumper Setting Default Selected
J1 OFF * Port 1 RS-485 EOL
terminator is not active
ON Port 1 RS-485 EOL
terminator is active
J2
Position 5 Reader 1 Power terminals
provides 5 VDC
Position 12 Reader 1 Power terminal
provides 12 VDC
J3
Position 5 Reader 2 Power terminal
provides 5 VDC
Position 12 * Reader 2 Power terminal
provides 12 VDC
S8 S7 S6 S5 S4 S3 S2 S1 Selection
OFF OFF OFF OFF ON ADDRESS 1*
OFF OFF OFF ON OFF ADDRESS 2
OFF OFF OFF ON ON ADDRESS 3
OFF OFF ON OFF OFF ADDRESS 4
OFF OFF ON OFF ON ADDRESS 5
OFF OFF ON ON OFF ADDRESS 6
OFF OFF ON ON ON ADDRESS 7
OFF ON OFF OFF OFF ADDRESS 8
OFF ON OFF OFF ON ADDRESS 9
OFF ON OFF ON OFF ADDRESS 10
OFF ON OFF ON ON ADDRESS 11
OFF ON ON OFF OFF ADDRESS 12
OFF ON ON OFF ON ADDRESS 13
OFF ON ON ON OFF ADDRESS 14
OFF ON ON ON ON ADDRESS 15
