PRO4200 Two-reader module User Guide, Document 800-25698V1 25
Inputs 6 and 7 Connected Cable # Cable Destination Conductor Color
Input 6
Pin #1
Input 6 Com
Pin #2
Input 7
Pin #3
Input 7 Com
Pin #4
Inputs 4 and 5 Connected Cable # Cable Destination Conductor Color
Relay 4 NC
Pin #1
Relay 4 Com
Pin #2
Relay 4 NO
Pin #3
Relay 5 NC
Pin #4
Relay 5 Com
Pin #5
Relay 5 NO
Pin #6
