2-Reader Input Module Programming Guide
Relay 0 Com
Pin #6
Relay 0 NC
Pin #7
Relay 1 No
Pin #8
Relay 1 Com
Pin #9
Relay 1 NC
Pin #10
Reader 1
WIN-PAK Reader 1(the reader address used in the WIN-PAK hardware setup)
VDC Select J2 5 Volt Connected Cable # Cable Destination Conductor Color
DC Out ( + )
Pin #1
Red LED
Pin #2
Beeper Ctrl
Pin #3
Data - 1
Pin #4
Data - 0
Pin #5
Common
Pin #6
Note:
Reader 0 is Reader 1 in WIN-PAK
Door 2 Input / Output Connected Cable # Cable Destination Conductor Color
Input 2
Pin #1
Input 2 Com
Pin #2
Input 3
Pin #3
Input 3 Com
Pin #4
Relay 2 No
Pin #5
Relay 2 Com
Pin #6
Relay 2 NC
Pin #7
Relay 3 No
Pin #8
Relay 3 Com
Pin #9
Relay 3 NC
Pin #10
Reader 2
WIN-PAK Reader 2 (the reader address used in the WIN-PAK hardware setup)
VDC Select J2 5 Volt Connected Cable # Cable Destination Conductor Color
DC Out ( + )
Pin #1
Red LED
Pin #2
Beeper Ctrl
Pin #3
Data - 1
Pin #4
Data - 0
Pin #5
Common
Pin #6
Note:
Reader 1 is Reader 2 in WIN-PAK
Door 1 Input / Output Connected Cable # Cable Destination Conductor Color
